HGSY Large Standard Aluminum
Part Name: HGSY
Part Number: 11240031
Unit Regular Price: $113.00
Unit Sale Price: $56.50
Specifications
Description
HGSY is our best snow and ice chock. It is a large heavy duty molded aluminum wheel chock with a heel-to-toe length that allows for a steeper line of force between axle and rear teeth. This wheel chocks enhanced coefficient of friction makes it a great winter safety solution.HGSY features a hand-grab opening which allows for fast placement and retrieval. A flanged base allows for a full range of bracket options. It is commonly used for loading docks, utility vehicles, and fire trucks.
HGSY features a powder coated Hi-Vis yellow finish.
Best Use
HEAVY TRUCKS: Liquefied gas tankers, Utility trucks, Large trailers, Municipal Transit Buses.Design
- Material:
- Aluminum
- Size:
- 8"H x 8.5"W x 12"L
- Weight:
- 6 lbs.
- ItemNo.:
- 11240031
Function
- Tire Size Rating:
- BEST FIT: Common Commercial Tires (22.5R)
MAXIMUM DIAMETER: 46 inches - Performance Rating:
- 16 % single chock usage, Over 30% paired usage. ALWAYS USE IN PAIRS AGAINST THE GRADE.
- Test to Failure:
- Exceeds SAE Standard J348 when used in pairs.
Design Calculations - Equilibrium Method Considered.
Parameters Given: 80,000 GVW Vehicle, 30% Grade. - Features:
- High-Vis Bright Yellow. Unbreakable Molded Aluminum Construction. High Adhesion and High Capacity. Yellow Powder Coat.
